NEW Chiropro PLUS

NEW Chiropro Plus Pure Simplicity

Simplicity. The cornerstone of the new implant motor developed by Bien-Air Dental. General dental practitioner or experienced surgeon, are you seeking a fast, simple and efficient solution for your implant dentistry procedures? Look no further than the Chiropro. Your perfect solution for precise and smooth placement of implants.

Reference:

Chiropro PLUS 3rd Gen set with Micro-Series CA 20:1 L 1700709-001

Chiropro PLUS 3rd Gen set with Micro-Series CA1:2.5L 1700751-001

Chiropro PLUS 3rd Gen without CA 1700710-001

Click to
explore

Technical Data

Chiropro PLUS 3rd Gen iChiropro Chiropro 3rd Gen
Control Knob (sterilisable)-
Implant placement
Built-in surgical procedures--
Surgical protocols->300-
Guided surgery protocols--
Digital workflow (import data from planning software CodiagnostiXTM) --
Exportable surgical report--
Max. Torque at the rotary instrument in implant mode 80 Ncm70 Ncm 70 Ncm
Dimensions L x W x H240mm x 240mm x 102mm242mm x 244mm x 102mm240mm x 240mm x 102mm
Weight2,2 Kg2,8 Kg2,2 Kg
Device warranty 2 to 3 years 1 2 to 3 years 1 2 to 3 years 1
MX-i specificationsMX-i LED 1600755-001
Self-ventilated
MX-i LED 1600755-001
Self-ventilated
MX-i LED 1601008-001
Non self-ventilated
Micromotor Dimensions ø x L23 x 91mm23 x 91mm23 x 83mm
Micromotor Weight115g115g110g
Reference Chiropro PLUS 3rd Gen set
without CA 1700710-001

Chiropro PLUS 3rd Gen set with
Micro-Series CA 20:1 L
1700709-001

Chiropro PLUS 3rd Gen set with
Micro-Series CA 1:2.5 L
1700751-001
iChiropro set with Micro-Series
CA 20:1 L
1700440-001
Chiropro 3rd Gen set without CA
1700708-001

Chiropro 3rd Gen set with
Micro-Series CA 20:1 L
1700707-001
Chiropro PLUS 3rd Gen
Control Knob (sterilisable)
Implant placement
Built-in surgical procedures -
Guided surgery protocols -
Digital workflow (import data from planning software CodiagnostiXTM) -
Exportable surgical report -
Max. Torque at the rotary instrument in implant mode 80 Ncm
Dimensions L x W x H 240mm x 240mm x 102mm
Weight 2,2 Kg
Device warranty 2 to 3 years 1
MX-i specifications MX-i LED 1600755-001
Self-ventilated
Micromotor Dimensions ø x L 23 x 91mm
Micromotor Weight 115g
Reference Chiropro PLUS 3rd Gen set
without CA 1700710-001

Chiropro PLUS 3rd Gen set with
Micro-Series CA 20:1 L
1700709-001

Chiropro PLUS 3rd Gen set with
Micro-Series CA 1:2.5 L
1700751-001
iChiropro
Implant placement
Built-in surgical procedures
Surgical protocols >300
Guided surgery protocols
Digital workflow (import data from planning software CodiagnostiXTM)
Exportable surgical report
Max. Torque at the rotary instrument in implant mode 70 Ncm
Dimensions L x W x H 242mm x 244mm x 102mm
Weight 2,8 Kg
Device warranty 2 to 3 years 1
MX-i specifications MX-i LED 1600755-001
Self-ventilated
Micromotor Dimensions ø x L 23 x 91mm
Micromotor Weight 115g
Reference iChiropro set with Micro-Series
CA 20:1 L
1700440-001
Chiropro 3rd Gen
Control Knob (sterilisable)
Implant placement
Built-in surgical procedures -
Guided surgery protocols -
Digital workflow (import data from planning software CodiagnostiXTM) -
Exportable surgical report -
Max. Torque at the rotary instrument in implant mode 70 Ncm
Dimensions L x W x H 240mm x 240mm x 102mm
Weight 2,2 Kg
Device warranty 2 to 3 years 1
MX-i specifications MX-i LED 1601008-001
Non self-ventilated
Micromotor Dimensions ø x L 23 x 83mm
Micromotor Weight 110g
Reference Chiropro 3rd Gen set without CA
1700708-001

Chiropro 3rd Gen set with
Micro-Series CA 20:1 L
1700707-001

1 2-year standard warranty and 1-year optional warranty available through Bien-Air’s PlanCare extended warranty program.

Maintenance

PREPARATION
A.

REMOVING THE INSTRUMENT

  • Remove the rotary instrument from the chuck mechanism
  • Disconnect the contra-angle from the motor
B.

PRE-DISINFECTION

  • External disinfection

Do not immerse the instrument in a disinfectant bath.

CLEANING
A.

CLEAN UNDER RUNNING WATER AT <38°C

B.

REMOVING DIRT/DEPOSITS

  • Carefully remove all traces of dirt or deposits from the nozzles using the Bien-Air cleaning wire
  • Dry the nozzles with compressed air then dry the rest of the instrument with a cloth

Do not immerse in an ultrasonic cleaner

C.

INTERNAL CLEANING WITH AQUACARE

  • Shake the Aquacare before use
  • Use the Aquacare attachment 1
  • Keep the tip of the instrument pointing down and protect with an absorbent cloth; press the Aquacare button down for 2 seconds
  • Use the Aquacare attachment 3
  • Keep the tip of the instrument pointing down and protect with an absorbent cloth; press the Aquacare button down for 1 second
D.

INTERNAL AND EXTERNAL CLEANING WITH SPRAYNET

  • Shake the Spraynet before use
  • Use the Spraynet attachment
  • Keep the tip of the instrument pointing down and protect with an absorbent cloth; press the Spraynet button down for 1 second
  • Clean the exterior of the contra-angle with a cloth soaked in Spraynet
DISINFECTION
A.

DISINFECTION USING SURFACE DISINFECTANT (follow the manufacturer's instructions for use)

Do not immerse the instrument in a disinfectant bath

OR
B.

THERMAL DISINFECTION (follow the manufacturer's instructions for use)

LUBRICATION
A.

LUBRICATION WITH LUBRIFLUID

  • Shake the Lubrifluid before use
  • Use the Lubrifluid attachment 1
  • Keep the tip of the instrument pointing down and protect with an absorbent cloth; press the Lubrifluid button down for 1 second
  • Then, run an operating test for 30 seconds at a low speed to remove any surplus lubricant
  • Store immediately: store the instruments with the tip pointing downwards so that any oil residues can flow out
STERILISATION
A.

PLACE THE CONTRA-ANGLE IN A STERILISATION BAG

B.

STERILISE IN ACCORDANCE WITH THE MANUFACTURER'S INSTRUCTIONS

  • Instruments bearing the "135°C" symbol can be sterilised in an autoclave

Only sterilise instruments which have been cleaned and lubricated
