Simplicity: the cornerstone of the new surgical motor developed by Bien-Air Dental. We do not need to calibrate our motor.
We do not need to calibrate our motor: the MX-i motor & 20:1 contra-angle have been validated to remain extremely accurate over a 1600 Sterilization-cycle life.
HP 1:2 designed specifically for impacted 3rd molar
INTUITIVE CONTROL KNOB
PATENTED IRRIGATION SYSTEM
EASY-TO-CLEAN DEVICE
CA 1:2.5 L designed for apicectomy, crown lenghtening, hemisection
CA 20:1 L designed for implantology
MX-i LED PLUS integral cooling fan
HP 1:2 designed specifically for impacted 3rd molar
Intuitive control knob
Patented irrigation system
EASY-TO-CLEAN DEVICE
CA 1:2.5 L designed for apicectomy, crown lenghtening, hemisection
CA 20:1 L designed for implantology
Integral cooling fan MX-i LED PLUS micromotor supports use of HP 1:2 for high-speed impacted 3rd Molar (Wisdom Tooth) extraction.
High torque The system allows up to 80 Ncm torque with 20:1 CA.
Speed stability High Torque quantity does not equal stable mechanical power. OMS is the most stable motor in low RPM (implant placment) ever measured, providing the user with confidence unmatched by competition.
Handpiece PM 1:2 Designed specifically for impacted 3rd molar
CUTTING TIME
The high rotational speed reduces cutting time by 70 % (12 seconds to completely section a tooth), while significantly reducing the force required.
Bur guard Technology
The PM 1:2 is also equipped with a bur guard preventing fluid infiltration in both the handpiece and the motor. The risk of overheating and premature handpiece failure is significantly minimized.
Intuitive control knob
With its single rotary knob, navigation is easier than ever before. Simply turn the knob to scroll through the menus, then click to confirm your choice.
New intuitive control for simplified daily use and reduced treatement time
Simple choice of surgical protocol and speed/torque settings in just 3-5 steps
Patented irrigation system
All our systems are equipped with a highly practical peristaltic pump, designed and patented by Bien-Air. Our irrigation lines incorporate an insertion support ensuring very easy handling and optimal hygiene.
User-friendly and comfortable pump system
Flow rate adjustable between 30 and 150ml/min
Safe and sterile : no contact between pump and liquid
Easy to clean
The single rotary knob is easy to remove from the unit for sterilization. In addition, the control panel is protected by highly resistant glass that is easy to clean.
Console interface made of tempered glass shock-resistant and easy to clean
Detachable and sterilizable knob
NEW Contra-angle
CA 1:2.5
The new CA 1:2.5 L Micro-Series is the gold standard contra-angle for surgery and periodontics.
Thanks to its speed increasing ratio, the CA 1:2.5 L Micro-Series can be used for a wide range of clinical applications : apicectomy, crown removal and crown lengthening.
With the irrigation line routed inside the CA 1:2.5 L Micro-Series, you have complete freedom of movement, with nothing to obstruct your handling of the instrument.
Connected to the MX-i PLUS micromotor, the CA 1:2.5 L Micro-Series offers you perfect balance and unrivalled ease of use.
Multi-strand optical glass technology
Bench test for durability: over 1500 cycles at 70 Ncm
1 - With the irrigation line routed inside the CA 1:2.5 L Micro-Series, you have complete freedom of movement, with nothing to obstruct your handling of the instrument.
2 - Connected to the MX-i PLUS micromotor, the CA 1:2.5 L Micro-Series offers you perfect balance and unrivalled ease of use.
3 - Multi-strand optical glass technology
Bench test for durability: over 1500 cycles at 70 Ncm
Durability
The drive system of the CA 20:1 L contra-angle has been optimized to withstand more than 1600 uses @70 Ncm. This substantially increases the instrument’s service life.
ACCU-CHUCKTM BUR-LOCKING AND ROTATION DRIVE MECHANISM
This provenbur-locking and vibration-canceling system vouches for optimal stability and precision, no matter the rotational speed. Assembled with Bien-Air's Soft PushTM button, bur release is quick and easy.
MICRO-SERIES
Bien-Air's new generation Micro-Series models ally innovation with compact design, resulting in improved power and maneuverability. Up to 30% shorter and 23% lighter than traditional models, they have an easy grasp that allows for optimal work comfort with less strain on the hand, arm, and shoulder.
Your data and torque values will remain visible on the device display after you stop the motor.
This enables you to document and copy the data into your patient files.
When and how do I have to calibrate my device?
Your ProImplant does not need any calibration, because of the minimized lost in torque transmission (+/-5%), which makes the device potentially the most precise on the market
Can I replace my control knob?
Yes. You can easily replace and sterilize your knob. To order a new control knob please contact your local Bien-Air sales point. The reference number is REF 1307031-001.
Can I increase the torque during surgery without touching the console?
Yes. You can remotely boost your torque via the foot pedal. Torque is increased by 5 Ncm each time. The operation can be repeated several times, until the maximum torque value is reached.
